Mphindi. Dongosolo:1 Piece/Pieces
Chitsanzo Cha: MG4700S01-1
Mtundu: Rkhslcd
Kukonzekera: 220k
Malo Oyamba: Mbale
Chiphaso: CD/ROSH/ISO9001
The mg4700s01-1 ili ndi lingaliro la 3840 (RGB) × 180, gawo la gawo la> 3: 1 (lilimi), ndipo pixel imakonzedwa mu mikwingwirima ya RGB. Kukula kwake kowonekera ndi 1192.3 × 55.89 (W × H) mm, ndipo kukula kwakunja ndi 1208.12 × 72.59 (w × H) mm mm mm mm mm mm mm mm mm mm mm mm mm mm mm mm mm mm mm mm mm mm. Kutentha kwa mg4700s01-1 ndi 0 ~ 50 ° C, ndipo kutentha kosungirako ndi -20 ~ 60 ° C.
[Ntchito imodzi yosiya, ntchito zapadziko lonse lapansi ndi thandizo lakwanuko]
Nyenyezi yokwera imapereka makasitomala omwe ali ndi ntchito yogula imodzi, ndipo zinthu zatha kuyesera zolimbitsa thupi kuti zitsimikizire kuti mtunduwo umakwaniritsa zokambirana; Ndipo khazikitsani dongosolo labwino kwambiri molingana ndi miyezo yapadziko lonse lapansi. Ntchito Zapadziko Lonse, kuti mupereke luso laukadaulo labwino, lothandizira malonda ndi ntchito zamabizinesi.
| brand | CSOT | Model name | MG4700S01-1 |
| size | 47inch | Screen type | a-Si TFT-LCD,LCD module |
| resolution ratio | 3840(RGB)×180 81PPI | Pixel configuration | RGB vertical bar |
| Display Area | 1192.3×55.89(H×V)mm | Surface treatment | Fog surface(Haze 25%) |
| Visual size | / | Contrast Ratio | 3000:1 (Typ.) (TM) |
| Brightness(cd/m²) | 500cd/m²(Typ.)or customized | Outline dimension | 1208.12×72.59 (H×V)mm |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) | work environment | Storage temperature: -20 to 60 °C Operation Temperature: 0 to 50 °C |
| Signal interface | V-by-One 8 lane,51 pins,erminal | ||
| supply voltage | 12.0V (Typ.) |
Ma tag otentha: Csot mg4700s01-1 lcd moudle, China, fakitale, mtengo wotsika mtengo, kunja inchi, mainchesi 55 panja TV
