15.4 inchi Samsung ltn154x9-l01

Mphindi. Dongosolo:1 Piece/Pieces

Zizindikiro Zogulitsa
Kuyika & Kutumiza
Other information

Zizindikiro Zogulitsa

Chitsanzo Cha: LTN154X9-L01

Kuyika & Kutumiza

Kugulitsa Units:

Piece/Pieces

Kuyambitsa Zoyambitsa

Ltn154x9-l01 modukiza iyi ili ndi chitsime cha CCFL, palibe woyendetsa, osakhudza. Mawonekedwe ake ndi: malo odyera. Kutentha kwake ndikuyenda 0 ~ 50 ° C, ndipo kutentha kwake kusungidwa ndi -20 ~ 60 ° C.

Matenda a LTN154X9-L017 (RGB) × 800 (WXGA), gawo la ma pixel limakonzedwa mu mikwingwirima ya RGB. Kukula kwake kowoneka bwino ndi 331.2 × 207 (kutalika kwake) mm, kutalika) × 226 (kutalika) × 7 (kutalika) mm. Kuchitiridwa kwagalasi (haze 0%), zokutira zovuta (3h).

10.1 inch panel

Q: Ogulitsa anu ndi ogulitsa ndi chiyani?

A: Pankhani ya malonda oyambira, tili ndi gulu logulitsa laukadaulo komanso gulu laukadaulo, omwe akufuna kuyankha mafunso anu pasanathe maola 24.FOR pambuyo - ntchito yogulitsa, kugwiritsa ntchito ndikusintha ma module owonongeka.

Q: Ndingapeze bwanji malonda oyenera?

Yankho: Chonde titumizireni zomwe mukufuna, tikupangira zinthu zathu zokhazikika, ngati sizikukwanira, tichita kusintha kofunikira & kusinthasintha.

Kuwala kwambiri LCD

brand	SAMSUNG	Model name	LTN154X9-L01
size	15.4 inch	Screen type	a-Si TFT-LCD,LCD module
resolution ratio	1280(RGB)×800	Pixel configuration	RGB vertical bar
Display Area	331.2×207(H×V)mm	Surface treatment	Glare (Haze 0%), Hard coating (3H)
Visual size	335.0×210.7(H×V)mm	Contrast Ratio	600:1 (Typ.) (TM)
Brightness(cd/m²)	500cd/m²(Typ.)or customized	Outline dimension	344×226×7(H×V×D)mm
Viewing Angle	65/65/50/50 (Typ.)(CR≥10)	work environment	Storage temperature: -20 to 60 °C Operation Temperature: 0 to 50 °C
Signal interface	LVDS (1 ch, 6-bit) ,erminal,30pins
supply voltage	12.0V (Typ.)
