Mphindi. Dongosolo:1 Piece/Pieces
Chitsanzo Cha: LQ150X1LW96
Matenda a LQ150x1lw96 ndi 1024 (RGB) × 768 (XGA), gawo la ma pixel limakonzedwa mu mikwingwirima ya RGB. Gawo lowonetsera la LQ150X1LW96 ndi 304.128 × 228.096 (w ng) mm, ndi × 10,5 (h) × 10.1 (d) mm. Matte kumaliza, zokutira molimba (3h), kulemera kwa 950g (max.)
Kukunja kwa Mbali Kumakhala Kopesidwa Kwathunthu, Kutentha kwake ndikukhala -20 ~ 7 ° C, ndipo kutentha kwake kosungira ndi -25 ° C, zomwe ndizoyenera kulingalira za mafakitale ndi zamankhwala.
| brand | Sharp | Model name | LQ150X1LW96 |
| size | 15inch | Screen type | a-Si TFT-LCD,LCD module |
| resolution ratio | 1024(RGB)×768 [XGA] 85PPI | Pixel configuration | RGB vertical bar |
| Display Area | 304.128×228.096mm(H×V) | Surface treatment | Fog surface，Hard coating (3H) |
| Visual size | 307.2×231.1mm(H×V) | Contrast Ratio | 1500:1 (Typ.) (TM) |
| Brightness(cd/m²) | 500cd/m²(Typ.)or customized | Outline dimension | 326.5×253.5×10.1(H×V×D)mm |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) | work environment | Storage temperature: -25 to 70 °C Operation Temperature: -20 to 70 °C |
| Signal interface | LVDS (1 ch, 6/8-bit),erminal,20 pins | ||
| supply voltage | 3.3V (Typ.) |
Q: Kodi ndinu opanga (fakitale)?
Y: Inde, ndife. Komanso oem / odm ntchito yomwe ilipo pano. Ndikusangalala kupereka yankho labwino kwambiri kwa inu.
Q: Ndingagule zitsanzo kuti nditsimikizire?
Yankho: Inde, khalani omasuka kulumikizana nafe.
Ma tag otentha: LQ150x1lw96 STRNE TFNE LCD Panel Screen, China, Wotsekemera, Wosachedwa, Wink Screen Screen, TV yakumanja, 1000Nets LCD Screen
15 "lq104v1dg62 550 Nit TFT
15inch lakuthwa LQ150X1LG96 TFTS LVDS
