Mphindi. Dongosolo:1 Piece/Pieces
Chitsanzo Cha: LQ156M1LG21
LQ156M11 ili ndi lingaliro la 1920 (RGB) × 1080 (FHD), gawo la mapilogalamuwo.
Kukula kwa LQ156m11.1.16 × 193.59 (w ng × 97 (D) mm, Pamtunda mankhwala matte, zolimba (3h), net kulemera 950g (max.)
Pankhani ya m'mbuyo, gwero lowunikira lowala limagwiritsidwa ntchito, ndipo moyo wa Kuwala ndi maola 50K, kutentha kwa LQ156M21 ndi 0 ~ ndi 30 ° ° C.
| brand | Sharp | Model name | LQ156M1LG21 |
| size | 15.6inch | Screen type | a-Si TFT-LCD,LCD module |
| resolution ratio | 1920(RGB)×1080 FHD | Pixel configuration | RGB vertical bar |
| Display Area | 344.16×193.59(H×V)mm | Surface treatment | Fog surface，Hard coating (3H) |
| Visual size | 349.0×198.4(H×V)mm | Contrast Ratio | 800:1 (Typ.) (TM) |
| Brightness(cd/m²) | 600cd/m²(Typ.)or customized | Outline dimension | 370×217×9.8(H*V*D) mm |
| Viewing Angle | 80/80/80/65 (Typ.)(CR≥10) | work environment | Storage temperature: 0 to 70 °C Operation Temperature: -30 to 70 °C |
| Signal interface | 30 pins LVDS (2 ch, 8-bit),erminal |
|
|
| supply voltage | 3.3V (Typ.) |
|
|
Ma tag otentha: lq156m21 New Terf-LCD yatsopano, China, fakitale yotsika mtengo, 55 mainchesi owala, 49 inchi, chojambula chowala , LCD Panel, LCD module, kuwonekera kowoneka bwino.
