Mphindi. Dongosolo:1 Piece/Pieces
Chitsanzo Cha: MG2350S01-1
Kutentha kwa mg2350s01-1 ndi 0 ~ 50 ° C, ndipo kutentha kosungirako ndi -20 ~ 60 ° C. Ndioyenera chizindikiro cha digito ndikudula screen.
Kuthetsa kuwonekera kwa mg2350s01-1 ndi 1920 (RGB) × 360, Kukula kwake ndi 596.6) matte (Haze 25%).
MG2350S001
| brand | CSOT | Model name | MG2350S01-1 |
| size | 23.5inch | Screen type | a-Si TFT-LCD,LCD module |
| resolution ratio | 1920(RGB)×360 | Pixel configuration | RGB vertical bar |
| Display Area | 584.64×109.62(H×V)mm | Surface treatment | Fog surface(Haze 25%) |
| Visual size | / | Contrast Ratio | 4000:1 (Typ.) (TM) |
| Brightness(cd/m²) | 500cd/m²(Typ.)or customized | Outline dimension | 596.42×122.67(H×V)mm |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) | Backlight type | WLED,Including LED driver |
| Signal interface | 30 pins LVDS (2 ch, 8-bit)，erminal | work environment | Storage temperature: -20 to 60 °C Operation Temperature: 0 to 50 °C |
| supply voltage | 12.0V (Typ.) |
|
|
Ma tag otentha: 23,5 , tsegulani ma module a LCD , LCD Panel, LCD module, kuwonekera kowoneka bwino.
