12.3 "Av123z7m-N11 Ikuwunikira gawo la LCD

Mphindi. Dongosolo:1 Piece/Pieces

Zizindikiro Zogulitsa
Kuyika & Kutumiza
Other information

Zizindikiro Zogulitsa

Chitsanzo Cha: AV123Z7M-N11

Kuyika & Kutumiza

Kugulitsa Units:

Piece/Pieces

Kuyambitsa Zoyambitsa

Av123z7m-N11, 12.3-inch madzi a galasi ndi A-ST Kukula kwa malo owonetsera ndi 292.032 × 109.512 (kutalika kwake) mm, ndi sp) mm, ndi ng olemera ndi 520 ± 50g.

10.1 inchi

Q: Ndife ndani?

A: R-R-Star idachokera ku Shenzhen, China, ndife opanga luso lakumapeto likulunga LCD, titha kupereka kuchokera ku ma module a LCD, pali antchito 20 azaka zambiri. Kampaniyo yadutsa iso9001 / ISO14001 / CCC / CE / FCC / ALE NDI DZIKO LAPANSI America, Africa, Middle East, Central Americancond ndi South America ndi Oceialia. Timakhulupirira kuti ngati mutipatsa mwayi wopita ku China.

Q: Kodi ndinu opanga (fakitale)?

Y: Inde, ndife. Komanso oem / odm ntchito yomwe ilipo pano. Ndikusangalala kupereka yankho labwino kwambiri kwa inu.

Q: Kodi tingatsimikizire bwanji mtundu?

Yankho: Kuyendera komaliza musanatumizidwe;

brand	BOE	Model name	AV123Z7M-N11
size	12.3 inch	Screen type	a-Si TFT-LCD,LCD module
resolution ratio	1920(RGB)×720 167PPI	Pixel configuration	RGB vertical bar
Display Area	292.032(H)×109.512(V) mm	Surface treatment
Visual size	295.03(H)×112.51(V) mm	Contrast Ratio	1000:1 (Typ.) (TM)
Brightness(cd/m²)	800cd/m²(Typ.)or customized	Outline dimension	307.9(H)×130.27(V)mm
Viewing Angle	80/80/80/80(Min.)(CR≥10)
Signal interface	LVDS (2 ch, 8-bit),41 pins, erminal
work environment	Storage temperature: -40 to 90 °C Operation Temperature: -30 to 85 °C
