Zizindikiro Zogulitsa

Chitsanzo Cha: TDA150-005V01

Kuyika & Kutumiza

Kugulitsa Units:

Piece/Pieces

Kuyambitsa Zoyambitsa

TDA150-005v01 A-si Tft-LCD 15-inch Madzi a Crystal, mawonekedwe owoneka bwino, kuphatikizapo driver wotsogola, matte pamtunda. Kutentha kwake ndikukhala -20 ~ 70 ° C, ndipo kutentha kwake kosungira ndi -30 ~ 80 ° C. Chiwonetsero chowonetsera ndi 1600 (RGB) × 1200 (UXGA), ndipo ma pixel amakonzedwa mu mikwingwirima ya RGB. Kukula kwake kowonekera ndi 304.8 × 228.6 (W × H) mm, ndipo gawo lakunja ndi 317.4 (w) × 242 (H) mm.

Ndi gwero lowala lowala ndi nthawi ya maola 30k, kuphatikiza madalaivala otsogozedwa. TDA10-005V01

15-2

Q: Ndife ndani?

A: R-R-Star idachokera ku Shenzhen, China, ndife opanga luso lakumapeto likulunga LCD, titha kupereka kuchokera ku ma module a LCD, pali antchito 20 azaka zambiri. Kampaniyo yadutsa iso9001 / ISO14001 / CCC / CE / FCC / ALE NDI DZIKO LAPANSI America, Africa, Middle East, Central Americancond ndi South America ndi Oceialia. Timakhulupirira kuti ngati mutipatsa mwayi wopita ku China.

Q: Kodi ndinu opanga (fakitale)?

Y: Inde, ndife. Komanso oem / odm ntchito yomwe ilipo pano. Ndikusangalala kupereka yankho labwino kwambiri kwa inu.

Q: Kodi tingatsimikizire bwanji mtundu?

A: Kuyendera komaliza musanatumizidwe.

brand	BOE	Model name	TDA150-005V01
size	15 inch	Screen type	a-Si TFT-LCD,LCD module
resolution ratio	1600(RGB)×1200 [UXGA] 133PPI	Pixel configuration	RGB vertical bar
Display Area	304.8×228.6mm (H×V)	Surface treatment	Fog surface(Haze 25%)，Hard coating (3H)
Brightness(cd/m²)	500cd/m²(Typ.)or customized	Contrast Ratio	1000:1 (Typ.) (TM)
Viewing Angle	85/85/85/85 (Min.)(CR≥10)	Outline dimension	317.4 × 242 mm (H×V)
Signal interface	LVDS (2 ch, 8-bit) ,erminal, 40 pins
work environment	Storage temperature: -30 to 80 °C Operation Temperature: -20 to 70 °C

Kukula kofanana ndi mtundu wake ndi motere:

brand	BOE	Model name	RT150X0M-N10
size	15 inch	Screen type	a-Si TFT-LCD,LCD module
resolution ratio	1024(RGB)×768, XGA, 85PPI	Pixel configuration	RGB vertical bar
Display Area	304.8×228.6mm (H×V)	Surface treatment	Fog surface(Haze 25%)，Hard coating (3H)
Brightness(cd/m²)	1100cd/m²(Typ.)or customized	Contrast Ratio	1000:1 (Typ.) (TM)
Viewing Angle	80/80/80/80 (Min.)(CR≥10)	Outline dimension	326.5×253.5(H×V)
Signal interface	LVDS (1 ch, 8-bit) ,erminal, 20 pins
work environment	Storage temperature: -30 to 80 °C Operation Temperature: -20 to 70 °C

brand	BOE	Model name	DV150X0M-N16
size	15 inch	Screen type	a-Si TFT-LCD,LCD module
resolution ratio	1024(RGB)×768, XGA, 85PPI	Pixel configuration	RGB vertical bar
Display Area	304.128×228.096(H×V) mm	Surface treatment	Fog surface(Haze 25%)，Hard coating (3H)
Brightness(cd/m²)	600cd/m²(Typ.)or customized	Contrast Ratio	1000:1 (Typ.) (TM)
Viewing Angle	89/89/89/89(Min.)(CR≥10)	Outline dimension	326.5×253.5×9.7mm(H×V×D)
Signal interface	20 pins LVDS (1 ch, 8-bit) , erminal
work environment	Storage temperature: -30 to 80 °C Operation Temperature: -20 to 70 °C

brand	BOE	Model name	RV150U0M-N00
size	15 inch	Screen type	a-Si TFT-LCD,LCD module
resolution ratio	1600(RGB)×1200 [UXGA] 133PPI	Pixel configuration	RGB vertical bar
Display Area	304.8 × 228.6 mm (H×V)	Surface treatment	Fog surface(Haze 25%)，Hard coating (3H)
Visual size	307.2 × 231 mm (H×V)	Contrast Ratio	1000:1 (Typ.) (TM)
Brightness(cd/m²)	500cd/m²(Typ.)or customized	Outline dimension	317.4×242 mm(H×V×D)
Viewing Angle	85/85/85/85(Min.)(CR≥10)
Signal interface	LVDS (2 ch, 8-bit),40 pins, erminal
work environment	Storage temperature: -30 to 80 °C Operation Temperature: -20 to 70 °C
