Zizindikiro Zogulitsa

Chitsanzo Cha: EV101WXM-N81

Kuyika & Kutumiza

Kugulitsa Units:

Piece/Pieces

Kuyambitsa Zoyambitsa

EV101Wxm-N81 ndi gawo la 10.1-inch lcd pogwiritsa ntchito ukadaulo wa A-si tf-lcd. Imakhala ndi chimphepo chamkuwa, kuphatikizapo kuyendetsa ma driver oyendetsa, osakhudza. Sonyecture Canlo ndi 1280 (RGB) × 800 (WXGA), gawo la 25:10 (lalitali: ndi ma pixel amakonzedwa mu mikwingwirima ya RGB. Kukula kwake kowoneka bwino ndi 216.96 × 135.6 (kutalika) mm, kukula kwa 3,5.4 (kukula) mm, kulemera kwa intaneti 50g (Njira.). Pankhani yobwezera, izi zimagwiritsa ntchito gawo lopepuka lolowera ndi moyo wa maola 50k, kuphatikizapo driver wotsogolera. EV101wxm-N81 imagwiritsa ntchito ma LVD (1 Ch, 8-bit) mawonekedwe a 6) Kutsitsimula kwake kokhazikika kwa FV ndi 60hz. Imagwira ntchito pa -20 ° C mpaka 70 ° C ndi masitolo a ku -30 ° C mpaka 80 ° C. Kutengera chiwonetsero choyera choyera, moyo ndioposa maola 50,000.

R-Star idachokera ku Shenzhen, China, ndife opanga luso lakumapeto Unikani LCD, yopanga mafakitale owoneka bwino, LCD ya LCD ndikuwonetsa chiwonetsero cha LCD, LCD yotsika kwambiri ndi masamba ena apamwamba. Mwachidule, kukwera kwa zaka zopitilira 5 zowala bwino kwambiri, zaka kapangidwe kazinthu zazikulu za TFT Gawo, kafukufuku ndi chitukuko, zaka 10 zojambula zapamwamba kwambiri.

brand	BOE	Model name	EV101WXM-N81
size	10.1 inch	Screen type	a-Si TFT-LCD,LCD module
resolution ratio	1280(RGB)×800, WXGA, 149PPI	Pixel configuration	RGB vertical bar
Display Area	216.96×135.6(H×V)mm	Surface treatment	/
Visual size	233.2×152.9×10.4(H×V×D) mm	Contrast Ratio	900:1 (Typ.) (TM)
Brightness(cd/m²)	500cd/m²(Typ.)or customized	Outline dimension	233.2×152.9×10.4(H×V×D)mm
Viewing Angle	85/85/85/85 (Typ.)(CR≥10)
Signal interface	LVDS (1 ch, 8-bit) ,erminal, 20 pins
work environment	Storage temperature: -30 to 80 °C Operation Temperature: -20 to 70 °C

Njira yofananira ndi magawo ake ali motere

brand	BOE	Model name	EV101WUM-N20
size	10.1 inch	Screen type	a-Si TFT-LCD,LCD module
resolution ratio	1920(RGB)×1200, WUXGA, 224PPI	Pixel configuration	RGB vertical bar
Display Area	216.806×135.504mm(H×V)	Surface treatment	/
Visual size	/	Contrast Ratio	900:1 (Typ.) (TM)
Brightness(cd/m²)	600cd/m²(Typ.)or customized	Outline dimension	229.45×149.22(H×V)mm
Viewing Angle	80/80/80/80(Typ.)(CR≥10)
Signal interface	LVDS (1 ch, 8-bit) ,erminal, 45 pins
work environment	Storage temperature: -25 to 80 °C Operation Temperature: -20 to 70 °C

brand	BOE	Model name	AT101WSM-N11-58P0
size	10.1 inch	Screen type	a-Si TFT-LCD,LCD module
resolution ratio	1024(RGB)×600, WSVGA, 117PPI	Pixel configuration	RGB vertical bar
Display Area	222.72×125.28mm(H×V)	Surface treatment	Fog surface，Hard coating (3H)
Visual size	226×128.6(H×V)mm	Contrast Ratio	500:1 (Typ.) (TM)
Brightness(cd/m²)	500cd/m²(Typ.)or customized	Outline dimension	235×144.9×5.44mm(H×V×D)
Viewing Angle	80/80/60/70(Typ.)(CR≥10)
Signal interface	LVDS (1 ch, 6/8-bit) , 60 pins , FPC
work environment	Storage temperature: -30 to 80 °C Operation Temperature: -20 to 70 °C

brand	BOE	Model name	EV101WXM-N82
size	10.1 inch	Screen type	a-Si TFT-LCD,LCD module
resolution ratio	1280(RGB)×800 [WXGA] 149PPI	Pixel configuration	RGB vertical bar
Display Area	216.96 × 135.6 mm (H×V)	Surface treatment	/
Visual size	/	Contrast Ratio	900:1 (Typ.) (TM)
Brightness(cd/m²)	500cd/m²(Typ.)or customized	Outline dimension	228.6 ×149.2×6 mm (H×V×D)
Viewing Angle	85/85/85/85(Typ.)(CR≥10)
Signal interface	LVDS (1 ch, 8-bit) ,erminal, 40 pins
work environment	Storage temperature: -30 to 80 °C Operation Temperature: -20 to 70 °C
